VHF FM TRANSCEIVER
Rugged and Basic 2M with Powerful Audio!
207 memory channels
Other features
• WX channel and weather alert function (USA version only)
• Program, memory, skip, priority and tone scans
• Power save function
• BNC type antenna connector
• Automatic repeater function (USA version only)
• 1750Hz tone for European repeater access (IC-V80E only)
• TOT (time out timer) setting
• Repeater lockout and busy channel lockout
• PC programmable with optional CS-V80
• Transceiver-to-transceiver cloning (Optional)
• Direct keypad frequency entry
• DTMF autodial memories
• Auto power off
• LCD backlight
• Wide/narrow channel spacing
SPECIFICATIONS
• Type of emissions : F2D/F3E (FM)
• No. of memory Ch. : 207 (incl. 6 scan edges and 1 call)
• Operating Temp. range : –20˚C to +60˚C; –4˚F to +140˚F
(Radio only)
• Frequency stability : ±2.5ppm (–20˚C to +60˚C) at 25˚C
• Power supply : 7.2V DC
requirement
• Current drain (at 7.2V DC):
Tx High (5.5W) 1.4A typical
Rx Max. audio 310mA typ. (Internal SP, 16Ω load)
180mA typ. (External SP, 8Ω load)
Stand-by 65mA typical
Power save 20mA typical
• Antenna impedance : 50Ω (BN)
• Dimensions (W×H×D) : 58 × 112 × 30 mm;
(Projections not included) 29⁄32 × 413⁄32 × 13⁄16 in
• Weight (approx.) : 140g; 4.9oz (without battery pack)
360g; 12.7oz (with BP-264 and Ant
Output power (at 7.2V) : 5.5/2.5/0.5W (High/mid/low)
• Max. freq. deviation : ±5.0kHz/±2.5kHz (Wide/narrow)
• Spurious emissions : Less than –60dB
• External microphone : 3-conductor 2.5(d)mm (1⁄10″)/2.2kΩ
connector
• Sensitivity : 0.14μV typical (at 12dB SINAD)
• Squelch sensitivity : 0.1μV typical (threshold)
• Selectivity : 70dB/50dB typical (Wide/narrow)
• Intermodulation : 70dB/65dB typical (Wide/narrow)
• Spurious and image : 75dB typical
rejection
• Audio output power : 750mW typ. (Internal SP, 16Ω load)
(at 10% distortion) 450mW typ. (External SP, 8Ω load)
• External speaker : 3-conductor 3.5(d) mm (1⁄8″)/8Ω
GENERAL
|
